Quality Original BOE EV238FHM-N21 23.8inch 1920x1080 FHD TFT LCD Panel Screen SRGB High Brightness 600nits Industrial Imaging Display Module factory

Original BOE EV238FHM-N21 23.8inch 1920x1080 FHD TFT LCD Panel Screen SRGB High Brightness 600nits Industrial Imaging Display Module

Brand Name

BOE

Country Of Origin

Guangdong, China

Unit Price

$195/pieces 1-99 pieces

Product Details

Highlight:

boe tft lcd display

boe industrial tft display

1920x1080 tft lcd display

Type: TFT

Display Size: 23.8inch

Supplier Type: Original Brand

Backlight Type: 16S4P WLED , 50K Hours , No Driver

Resolution: 1920(RGB)x1080, FHD 92PPI, 1920(RGB)x1080, FHD 92PPI

Brightness: 600 Cd/m² (Typ.), 600cd/m2

Operating Temperature: Operating Temp.: 0 ~ 50 °C

Display Type: ADS, Normally Black, Transmissive

Mounting Type: Connector

Screen Size: 543.1(W)x317.4(H)x15.3(D) Mm

Communication Interface: LVDS (2 Ch, 8-bit) , 30 Pins Connector

Panel Type: A-Si TFT-LCD, LCM

Module Outsize(Mm): 543.1(W)x317.4(H)x15.3(D) Mm

Viewing Angle: 89/89/89/89 (Typ.)(CR≥10)

Interface: LVDS (2 Ch, 8-bit) , 30 Pins Connector

Touch Screen: Without

Application: Industrial Imaging Display

MPQ: 7pcs

Warranty: 12 Months

Product Description

Detailed Specifications And Features

Original BOE EV238FHM-N21 23.8inch 1920x1080 FHD TFT LCD Panel Screen SRGB High Brightness 600nits Industrial Imaging Display Module

Products Description

Panel Model	EV238FHM-N21	Panel Brand	BSDT
Size (inch )	23.8inch	Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 92PPI	Pixel Format	RGB Vertical Stripe
Module Outsize(mm)	543.1(W)×317.4(H) ×15.3(D) mm	Display Mode	ADS, Normally Black, Transmissive
LCD Active area(mm)	527.04(W)×296.46(H) mm	Response Time	14 (Typ.)(G to G)
Display Colors	16.7M 99% sRGB	Light Source	WLED , 50K hours , Without Driver
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Touch Screen	Without
Brightness	600 (Typ.)(cd/m²)	Power Supply	5.0V (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)	Used for	Industrial，Medical Imaging
Frame Ratio	60Hz	Enviroment	Storage Temp.: -20~ 60 °C
Frame Ratio	60Hz	Enviroment		Operating Temp.: -0 ~ 50°C
LCM Interface Type	LVDS (2 ch, 8-bit) , 30 pins Connector	FPC connector	UJU, IS100-L30O-C23, Pitch 1.0mm
