| Brand Name: | Mitsubishi |
| Model Number: | AA084SC01 |
| MOQ: | 1 |
| Price: | $310/pieces 1-99 pieces |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Panel Model | AA084SC01 | Panel Brand | Mitsubishi |
|---|---|---|---|
| Size | 8.4 inch | Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×600, SVGA 119PPI | Pixel Format | RGB Vertical Stripe |
| Module Dimensions | 199.5(W)×149(H)×10.2(D) mm | Display Mode | SWV, Normally Black, Transmissive |
| Active Area | 170.4(W)×127.8(H) mm | Response Time | 12/12 (Typ.)(Tr/Td) |
| Display Colors | 262K/16.7M 72% NTSC | Light Source | WLED, 100K hours, With LED Driver |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) | Touch Screen | Without |
| Brightness | 600 cd/m² (Typ.) | Power Supply | 3.3V (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) | Application | Industrial |
| Frame Rate | 60Hz | Interface Type | LVDS (1 ch, 6/8-bit), 20 pins Connector |
| FPC Connector | I-pex, 20186-020E-11F, Pitch 1.25mm | Environment | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80°C |
