AA084XD11 Mitsubishi 8.4 Inch Led Backlit TFT LCD Display Panel XGA 1024x768 1000cd/M2

Name: AA084XD11 Mitsubishi 8.4 Inch Led Backlit TFT LCD Display Panel XGA 1024x768 1000cd/M2
Brand: Shenzhen Wanshujie Photoelectric Technology Co., Ltd.
SKU: AA084XD11
Price: 50.00 USD
Availability: InStock

Brand Name:	Mitsubishi
Model Number:	AA084XD11
MOQ:	1
Price:	$470/pieces 1-99 pieces
Payment Terms:	L/C,D/A,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Panel Type:

A-Si TFT-LCD, LCM

Display Size:

8.4inch

Supplier Type:

Original Brand

Resolution:

1024(RGB)x768, XGA 152PPI

Module Outsize(mm):

199.5(H)x149(V) X10.2(D) Mm

Viewing Angle:

85/85/85/85 (Typ.)(CR≥10)

Brightness:

1000cd/m2

Contrast Ratio:

1000:1 (Typ.) (TM)

Interface:

LVDS (1 Ch, 6/8-bit) , 20 Pins Connector

Touch Screen:

Without

Light Source:

WLED [2 Strings] , 100K Hours , W/O Driver

Environment:

Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C

Application:

Industrial, Outdoor High Brightness

MPQ:

20pcs

Warranty:

12 Months

Packaging Details:

20pcs/Box

Highlight:

Mitsubishi led backlit tft lcd display

1000cd/M2 led backlit tft lcd display

Mitsubishi tft display panel

Product Description

Mitsubishi AA084XD11 8.4-Inch XGA Industrial Display

High-performance 8.4-inch TFT-LCD display module with 1024×768 XGA resolution, engineered for demanding industrial applications requiring ultra-high brightness and reliable operation across wide temperature ranges.

Key Features

1024×768 XGA resolution with 152 PPI for exceptional display clarity
1000 cd/m² ultra-high brightness for excellent visibility in bright environments
85/85/85/85 viewing angles with SWV display technology
LVDS interface with 20-pin connector for reliable data transmission
1000:1 contrast ratio for superior image quality
WLED backlight with 100,000 hours lifespan
262K/16.7M color support
Wide operating temperature range: -30°C to 80°C

Technical Specifications

Panel Model	AA084XD11	Panel Brand	Mitsubishi
Size	8.4 inch	Panel Type	a-Si TFT-LCD, LCM
Resolution	1024(RGB)×768, XGA 152PPI	Pixel Format	RGB Vertical Stripe
Module Dimensions	199.5(H)×149(V)×10.2(D) mm	Display Mode	SWV, Normally Black, Transmissive
Active Area	170.496(W)×127.872(H) mm	Response Time	12/12 ms (Typ.)(Tr/Td)
Display Colors	262K/16.7M	Light Source	WLED [2 strings], 100K hours
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)	Touch Screen	Without
Brightness	1000 cd/m² (Typ.)	Power Supply	3.3V (Typ.)
Contrast Ratio	1000:1 (Typ.)	Application	Industrial, Outdoor high brightness
Frame Rate	60Hz	Operating Temperature	-30°C to 80°C
Interface Type	LVDS (1 ch, 6-bit)	Storage Temperature	-30°C to 80°C
Connector	20 pins, JAE FI-SEB20P-HFE, Pitch 1.25mm

Applications

Industrial equipment and machinery
Automation equipment displays
Outdoor high brightness applications
CNC machine displays
Medical equipment
EV Charger Display
Industrial Control Display

Customization Options

Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include AR (Anti-Reflective), AF (Anti-Fingerprint), and AG (Anti-Glare). This display can be equipped with an HDMI driver board for easier debugging and evaluation, as well as for direct integration into your products. Optional industrial-grade capacitive touch available.

About Wan Display

Founded in 2019, Shenzhen Wanshujie Photoelectric Technology specializes in providing original screens from various brands and offers comprehensive touchscreen integration solutions. We focus on differentiated products and provide personalized customization services. With extensive industry experience and superior supply chain resources, we deliver fast, first-tier services to our clients.
