| Brand Name: | AUO |
| Model Number: | A104SN03 V1 |
| MOQ: | 1 |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
800x600 Industrial Device Display Module Produced by AUO.
The AUO A104SN03 V1 is a 10.4-inch 800*600 SVGA a-Si TFT-LCD panel with 350 cd/m² brightness, 500:1 contrast ratio, TTL + SPI interface, designed for industrial,Portable Navigaiton, Digital Photoframe, Portable DVD Player display applications.
Mass production began in Q4 2008. We are able to provide large quantities with competitive pricing and welcome your inquiries and orders.
| Parameter Category | Parameter Details | Parameter Value |
|---|---|---|
| Model Information | Manufacturer | AUO |
| Model Name | A104SN03 V1 | |
| Basic Information | Display Size | 10.4" |
| Panel Type | a-Si TFT-LCD, LCM | |
| Display Parameters | Resolution | 800(RGB)*600, 4:3, SVGA |
| Pixel Structure | RGB Vertical Stripe | |
| Display Area | 211.2(W)*158.4(H) mm | |
| Outline Size | 228.4(W)*175.4(H)*6.5(D) mm | |
| Brightness | 350 cd/m² (Typ.) | |
| Contrast Ratio | 500:1 (Typ.) (TM) | |
| Viewing Angle | 75/75/50/60 (Typ.)(CR≥10) | |
| View Direction | 6 o'clock | |
| Display Mode | TN, Normally White, Transmissive | |
| Response Time | 30 (Typ.)(Tr+Td) ms | |
| Display Colors | 262K/16.7M, 50% NTSC | |
| Frequency | 60Hz | |
| Structure & Appearance | Panel Weight | 400±20g |
| Surface | Antiglare, Hard coating (3H) | |
| Backlight & Power | Light Source | 3S12P WLED, 10K hrs, Without Driver |
| Power Usage | 3.4W (Max.) | |
| Input Voltage | 3.3/11/15/-7V (Typ.)(VCC/AVDD/VGH/VGL) | |
| Interface & Function | Interface | TTL (1 ch, 6/8-bit) + SPI, 60 pins FPC |
| Connector | FPC, Pitch 0.5,60 Pins | |
| Touch Screen | Without | |
| Application & Environment | Application | Industrial / Commercial Display |
| Environment | Operating Temp. -10 ~ 60 °C, Storage Temp. -20 ~ 70 °C |
Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include AR (Anti-Reflective), AF (Anti-Fingerprint), and AG (Anti-Glare). This display can be equipped with an HDMI driver board for easier debugging and evaluation, as well as for direct integration into your products.
Touchscreen integration solutions available upon request.
Founded in 2019, Shenzhen Wanshujie Photoelectric Technology specializes in providing original screens from various brands and offers comprehensive touchscreen integration solutions. We focus on differentiated products and provide personalized customization services. With extensive industry experience and superior supply chain resources, we deliver fast, first-tier services to our clients.
