BOE 32 inch 1920x1080 FHD TFT-LCD 75hz Transmittance 5% with Polarizer Matte Antiglare COF Built-in LCM Panel Type LCM

Brand Name:	BOE
Price:	$100/pieces 1-99 pieces

Detail Information

Product Description

Detail Information

Place of Origin:

China

Type:

TFT

Display Size:

32 Inch

Supplier Type:

Original Brand

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)x1080, FHD 69PPI

Module Outsize(mm):

708.4(H)x405.4(V)x1.36(D) Mm

Viewing Angle:

89/89/89/89 (Typ.)(CR≥10)

Brightness:

0 Cd/m² (Typ.)

Signal Interface:

LVDS (2 Ch, 8-bit) , 51 Pins Connector

Touch Panel:

Without

Transmittance:

5.0% (Typ.)(with Polarizer)

Application:

TV Sets

Environment:

Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20~ 60°C

Highlight:

boe tft lcd display

boe industrial tft display

1920x1080 tft lcd display

Product Description

Products Description

Panel Model	HV320FHB-N02	Panel Brand	BOE
Size (inch )	32Inch	Panel Type	a-Si TFT-LCD, CELL , FOB
Resolution	1920(RGB)×720 167PPI	Pixel Format	RGB Vertical Stripe
Module Outsize(mm)	708.4 × 405.4 × 1.36 (H×V×D)	Display Mode	ADSDS, Normally Black, Transmissive
LCD Active area(mm)	698.4(W)×392.85(H) mm	Response Time	8 (Typ.)(G to G) ms
Display Colors	16.7M 72% NTSC	Light Source	No B/L
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Transmissivity	5.0% (Typ.)(with Polarizer)
Brightness	0 cd/m² (Typ.)	Power Supply	12V (Typ.)
Contrast Ratio	1200 : 1 (Typ.) (TM)	Used for	TV sets
Frame Ratio	75Hz	Enviroment	Storage Temp.: -20 ~ 60 °C
Frame Ratio	75Hz	Enviroment		Operating Temp.: -0 ~ 60 °C
LCM Interface Type	LVDS (2 ch, 8-bit) , 51 pins Connector	FPC connector	UJU, IS050-C51B-C39-S，Pitch 0.5mm

Details Images

Company Profile

FAQ

Q1. What is your lead time? A: Stock: 5-15 days in general. No stock: 15-30 days after samples confirmed. Or please contact us by email for specific lead time base on your order quantities. Q2. How does your factory do regarding quality control? A: Quality is priority. We always attach great importance to quality control from the very beginning to the end: 1) All raw material we used are non-toxic, environmental-friendly; 2) Skillful workers pay great attention to each details in handling the producing and packing processes; 3) We have a professional QA/QC team to ensure the quality. Q3. Do you accept OEM or ODM order? A: Yes, we accept both OEM and ODM for customers. Q4. What are your terms of delivery? A: We can accept EXW, FOB, CIF, etc. You can choose one which is the most convenient for you. Q5. What is the payment way? A: TT, Pay Later, West Union,Online Bank Payment. Should you have other questions, please let us know. We’ll add answers here for your further references. Thank you.
