Quality 5" 640x480 VGA TFT-LCD Wide Temperature 5G Vibration Industrial Rugged Outdoor High Brightness Display Module TX13D04VM2CAA factory

5" 640x480 VGA TFT-LCD Wide Temperature 5G Vibration Industrial Rugged Outdoor High Brightness Display Module TX13D04VM2CAA

Brand Name

KOE/Hitachi

Country Of Origin

China Taiwan

MOQ

24 pieces

Unit Price

$100/pieces 24-239 pieces

Product Details

Highlight:

640x480 tft lcd display

640x480 industrial tft display

lcd industrial tft display

Type: TFT

Display Size: 5 Inch

Supplier Type: Original Brand

Backlight Type: WLED , 70K Hours , With LED Driver

Resolution: 640(RGB)x480, VGA 159PPI, 640(RGB)x480, VGA 159PPI

Brightness: 600 Nits, 600cd/m2

Operating Temperature: Operating Temp.: -30 ~ 80 °C

Brand: HITACHI / KOE

Display Type: TN, Normally White, Transmissive

Mounting Type: Connector

Screen Size: 119.4 X 89.1 X 9.8 (HxVxD)

Communication Interface: CMOS (1 Ch, 6-bit) , 40 Pins Connector

Panel Type: A-Si TFT-LCD, LCM

Module Outsize(Mm): 119.4(W)x89.1(H) X9.8(D) Mm

Viewing Angle: 70/70/60/60 (Typ.)(CR≥10)

Signal Interface: CMOS (1 Ch, 6-bit) , 40 Pins Connector

Touch Panel: Without

Application: Industrial, Outdoor High Brightness, Rugged Industry

Warranty: 12months

Input Voltage: 3.3V (Typ.)

Product Description

Detailed Specifications And Features

5" 640x480 VGA TFT-LCD Wide Temperature 5G Vibration Industrial Rugged Outdoor High Brightness Display Module TX13D04VM2CAA

Products Description

Panel Model	TX13D04VM2CAA	Panel Brand	Hitachi
Size (inch )	5inch	Panel Type	a-Si TFT-LCD, LCM
Resolution	640(RGB)×480, VGA 159PPI	Pixel Format	RGB Vertical Stripe
Module Outsize(mm)	119.4(W)×89.1(H) ×9.8(D) mm	Display Mode	TN, Normally White, Transmissive
LCD Active area(mm)	101.76(W)×76.32(H) mm	Response Time	45 (Max.)(Tr+Td)
Display Colors	262K 54% NTSC	Light Source	WLED , 70K hours , With LED Driver
Viewing Angle	70/70/60/60 (Typ.)(CR≥10)	Touch Screen	Without
Brightness	600 cd/m² (Typ.)	Power Supply	3.3V (Typ.)
Contrast Ratio	500:1 (Typ.) (TM)	Used for	Industrial, Rugged Industry
Frame Ratio	60Hz	Enviroment	Storage Temp.: -40 ~ 90 °C
Frame Ratio	60Hz	Enviroment		Operating Temp.: -30 ~ 80°C
		Vibration Level:	5.0G (49.0 m/s²)
LCM Interface Type	CMOS (1 ch, 6-bit) , 40 pins Connector	FPC connector	JAE, FA5S040HP1, Pitch 0.5mm
