| Brand Name: | NLT |
| Model Number: | NL192108AC18-01D |
| MOQ: | 1 |
| Price: | $205/pieces 1-99 pieces |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Panel Model | NL192108AC18-01D | Panel Brand | NEC |
|---|---|---|---|
| Size | 15.6 inch | Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 141PPI | Pixel Format | RGB Vertical Stripe |
| Module Dimensions | 363.8 × 215.9 × 6.8 mm (H×V×D) | Display Mode | UA-SFT, Normally Black, Transmissive |
| Active Area | 344.16 × 193.59 mm (W×H) | Response Time | 25 ms (Typ.) |
| Display Colors | 16.7M, 72% NTSC | Light Source | WLED, 50K hours, With LED Driver |
| Viewing Angle | 88/88/88/88 (Typ.) | Touch Screen | Without |
| Brightness | 400 cd/m² (Typ.) | Power Supply | 3.3V (Typ.) |
| Contrast Ratio | 800:1 (Typ.) | Application | Industrial |
| Frame Rate | 60Hz | Interface Type | eDP (2 Lanes), HBR1 (2.7G/lane), 40 pins Connector |
| Storage Temperature | -30°C to 80°C | Operating Temperature | -20°C to 70°C |
| Vibration Level | 2.0G (68.6 m/s²) | FPC Connector | I-pex, 20455-040E-02, Pitch 0.5mm |
