Industrial Equipment NLT NL8048BC24-09D 9-Inch TFT Display Module with 800x480 WVGA IPS LCD Screen and 2.0G Vibration

Name: Industrial Equipment NLT NL8048BC24-09D 9-Inch TFT Display Module with 800x480 WVGA IPS LCD Screen and 2.0G Vibration
Brand: Shenzhen Wanshujie Photoelectric Technology Co., Ltd.
SKU: NL8048BC24-09D
Price: 50.00 USD
Availability: InStock

Brand Name:	NEC
Model Number:	NL8048BC24-09D
MOQ:	1
Price:	$210/pieces 1-99 pieces
Payment Terms:	L/C,D/A,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Panel Type:

A-Si TFT-LCD, LCM

Display Size:

9inch

Supplier Type:

Original Brand

Resolution:

800(RGB)×480, WVGA 103PPI

Module Outsize(mm):

220.5(W)×136.5(H)×8.7(D) Mm

Viewing Angle:

88/88/88/88 (Typ.)(CR 10)

Brightness:

400cd/m2

Contrast Ratio:

800 : 1 (Typ.) (TM)

Interface:

LVDS (1 Ch, 6/8-bit) , 20 Pins Connector

Touch Panel:

Withtout

Application:

Industrial Equipment

Max. Ratings:

Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 M/s²)

MPQ:

10pcs

Warranty:

12 Months

Highlight:

9-Inch TFT Display Module

800x480 WVGA IPS LCD Screen

2.0G Vibration Industrial TFT Display

Product Description

Industrial Equipment NLT NL8048BC24-09D 9-Inch TFT Display Module

High-performance 9-inch TFT display module featuring 800x480 WVGA IPS LCD screen with 2.0G vibration resistance, designed for demanding industrial applications.

Product Overview

Model: NL8048BC24-09D | Brand: NEC

Display Size: 9-inch | Resolution: 800×480 WVGA (103 PPI)

Interface: LVDS 20-pin connector | Panel Type: a-Si TFT-LCD, LCM

Key Features

High Brightness
400 cd/m² typical brightness for clear visibility

Wide Viewing Angles
88/88/88/88 (CR≥10) for optimal viewing from multiple positions

Durable Construction
Vibration resistant up to 2.0G (19.6 m/s²)

Long Lifespan
WLED backlight with 70,000 hours typical lifespan

Technical Specifications

Parameter	Specification
Active Area	196.8 × 118.08 mm (W×H)
Module Dimensions	220.5 × 136.5 × 8.7 mm (H×V×D)
Display Colors	262K/16.7M (60% NTSC)
Contrast Ratio	800:1 (Typical)
Response Time	10/15 ms (Typical Tr/Td)
Power Supply	3.3V (Typical)
Operating Temperature	-20°C to 70°C
Storage Temperature	-30°C to 80°C
Frame Rate	60Hz

Applications

Ideal for industrial equipment and industrial monitoring systems. Mass production began in Q2 2010.

Customization Options

Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include:

AR (Anti-Reflective) coating
AF (Anti-Fingerprint) coating
AG (Anti-Glare) coating

Can be equipped with HDMI driver boards for simplified customer debugging and evaluation.

About Wan Display

Founded in 2019, Shenzhen Wanshujie Photoelectric Technology specializes in providing original screens from various brands and offers comprehensive touchscreen integration solutions. With extensive industry experience and superior supply chain resources, we deliver fast, first-tier services with personalized customization options.
