10.4inch NTSC RGB Industrial TFT Display LCD Color Monitor 640x480 VGA
10.4inch NTSC RGB Industrial TFT Display LCD Color Monitor 640x480 VGA
Brand Name
Sharp
Product Model
LQ104V1LG81
Country Of Origin
China
MOQ
1
Unit Price
$160/pieces 1-99 pieces
Product Details
Highlight:
RGB Industrial TFT Display
,NTSC Industrial TFT Display
,NTSC 10.4 tft lcd color monitor
Type:
TFT
Display Size:
10.4inch
Supplier Type:
Original Brand
Panel Type:
A-Si TFT-LCD, LCM
Resolution:
640(RGB)x480, VGA 76PPI
Module Outsize(Mm):
246.5(H)x179.3(V) X13(D) Mm
Viewing Angle:
80/80/60/80 (Typ.)(CR 10)
Brightness:
450cd/m2
Color Depth:
262K 50% NTSC
Touch Screen:
Without
Application:
Industrial
Refresh Rate:
60Hz
Signal Type:
LVDS (1 Ch, 6-bit) , Connector 20 Pins
Product Description
Detailed Specifications And Features
10.4" VGA TFT-LCD Sharp LQ104V1LG81 Industrial Display Module
High-performance 10.4-inch TFT-LCD display module designed for industrial applications with wide temperature operation and mechanical compatibility with LQ104V1DG61/LG61 models. This panel has been in mass production since Q3 2011.
Key Specifications
| Panel Model | LQ104V1LG81 | Panel Brand | Sharp |
| Size | 10.4 inch | Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 640(RGB)×480, VGA 76PPI | Pixel Format | RGB Vertical Stripe |
| Module Dimensions | 246.5(H)×179.3(V)×13(D) mm | Display Mode | TN, Normally White, Transmissive |
| Active Area | 211.2(W)×158.4(H) mm | Response Time | 35 ms (Typ.)(Tr+Td) |
| Display Colors | 262K, 50% NTSC | Light Source | WLED, 50K hours, With LED Driver |
| Viewing Angle | 80/80/65/80 (Typ.)(CR≥10) | Touch Screen | Without |
| Brightness | 450 cd/m² (Typ.) | Power Supply | 3.3V (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) | Application | Industrial |
| Frame Rate | 60Hz | Interface Type | LVDS (1 ch, 6-bit), 20 pins Connector |
| Operating Temperature | -30°C to 80°C | Storage Temperature | -30°C to 80°C |
| FPC Connector | Pitch 1.25mm |
Key Features
- Wide temperature range operation (-30°C to 80°C)
- High brightness 450 cd/m² for industrial environments
- Long-life WLED backlight with 50,000 hours lifespan
- LVDS interface with 20-pin connector
- Mechanically compatible with LQ104V1DG61/LG61 models
- Robust construction for demanding industrial applications
Technical Details
This Sharp LQ104V1LG81 display module features a 10.4-inch TFT-LCD panel with VGA resolution (640×480), delivering clear and reliable performance in industrial settings. The module operates across an extensive temperature range and includes built-in LED driver circuitry for optimal performance and longevity.
Customization Options
Available with cover glass using Corning Gorilla GG3 in various thicknesses. Surface treatments include AR, AF, and AG. Can be equipped with HDMI driver board for easy debugging and evaluation.
Why Choose Wan Display
Founded in 2019, Shenzhen Wanshujie Photoelectric Technology specializes in providing original screens of various brands and offers one-stop solutions for touchscreen integration. With extensive experience and advantageous supply resources, we provide clients with fast and superior first-tier services.
