| Brand Name: | AUO |
| Model Number: | G238HAN01.3 |
| MOQ: | 1 |
| Price: | $220/pieces 1-99 pieces |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
1920x1080 FHD Industrial , Medical Imaging Device Display Module Produced by AUO.
The AUO G238HAN01.3 is a 23.8-inch FHD industrial-grade LCD module with 600 cd/m² high brightness, AHVA wide viewing angle, anti-glare 3H hard coating, and a 50K-hour backlight, designed for long-duration use in industrial control, Medical Imaging, public kiosks, and commercial display applications.
Mass production began in Q4 2019. We are able to provide large quantities with competitive pricing and welcome your inquiries and orders.
| Parameter Category | Parameter Details | Parameter Value |
|---|---|---|
| Model Information | Manufacturer | AUO |
| Model Name | G238HAN01.3 | |
| Basic Information | Display Size | 23.8" |
| Panel Type | a-Si TFT-LCD, LCM | |
| Display Parameters | Resolution | 1920(RGB)*1080, FHD, 16:9 |
| Pixel Format | RGB Vertical Stripe | |
| Display Area | 527.04(W)*296.46(H) mm | |
| Outline Size | 543(W)*317.4(H)*11.65(D) mm | |
| Brightness | 600 cd/m² (Typ.) | |
| Contrast Ratio | 1000:1 (Typ.) (TM) | |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | |
| View Direction | Symmetry | |
| Display Mode | AHVA, Normally Black, Transmissive | |
| Response Time | 14 (Typ.)(G to G) ms | |
| Display Colors | 16.7M, 72% NTSC | |
| Frequency | 60Hz | |
| Structure & Appearance | Panel Weight | 2.30Kgs (Typ.) |
| Surface | Antiglare, Hard coating (3H) | |
| Backlight & Power | Light Source | 20S4P WLED, 50K hrs, Without Driver |
| Power Consumption | 27.1W (Typ.) | |
| Input Voltage | 5.0V (Typ.) | |
| Interface & Function | Interface | LVDS (2 ch, 8-bit), 30 pins Connector |
| Connector | STM,MSBKT2407P30HB,Pitch 1.0mm | |
| Touch Screen | Without | |
| Application & Environment | Application | Industrial / Commercial Display |
| Environment | Operating Temp. 0 ~ 50 °C, Storage Temp. -20 ~ 60 °C |
Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include AR (Anti-Reflective), AF (Anti-Fingerprint), and AG (Anti-Glare). This display can be equipped with an HDMI driver board for easier debugging and evaluation, as well as for direct integration into your products.
Touchscreen integration solutions available upon request.
Founded in 2019, Shenzhen Wanshujie Photoelectric Technology specializes in providing original screens from various brands and offers comprehensive touchscreen integration solutions. We focus on differentiated products and provide personalized customization services. With extensive industry experience and superior supply chain resources, we deliver fast, first-tier services to our clients.
