12.7-inch Ultra-Long Bar LCD Display Module with 2880×864 High Resolution and 120Hz High Refresh Rate

12.7-inch Ultra-Long Bar LCD Display Module with 2880×864 High Resolution and 120Hz High Refresh Rate
Brand Name
BOE
Product Model
NV127H4M-NX1
Country Of Origin
China
MOQ
1
Unit Price
US$ 66 / PC
Payment Method
,Western Union,T/T,D/P,D/A,L/C
Product Details
Highlight:

12.7-inch stretched bar LCD display

,

2880×864 high-resolution LCD module

,

120Hz refresh rate bar display
Screensize: 12.7 Inch
Aspectratio: 30:9
Resolution: 2880(RGB)×864 237PPI
Treatment: Hard Coating (3H)
Luminance: 500 Cd/m² (Typ.)
Contrast Ratio: 1200 : 1 (Typ.) (TM)
Viewingangle: 89/89/89/89 (Typ.)(CR≥10)
Colors: 16.7M 100% DCI-P3
Life Time: 15000 Hrs
Refresh Rate: 120Hz
Pin Number: 40 Pins (customizable）
Max. Ratings: Storage Temp.: -20 ~ 55 °C Operating Temp.: 0 ~ 50 °C
Mpq: 40pcs
Product Description
Detailed Specifications And Features
NV127H4M-NX1 12.7" 2880×864 Ultra-Long Bar LCD High Refresh Wide Gamut Industrial Gaming Secondary Display Module
Product Overview

BOE NV127H4M-NX1 industrial display module featuring ultra-wide bar design, high refresh rate, and professional color performance for demanding applications.


  • Original NV127H4M‑NX1 12.7-inch ultra‑wide bar LCD module
  • High resolution: 2880 × 864,clear and delicate image display
  • High refresh rate: 120Hz,smooth motion without lag
  • Wide color gamut: 100% DCI‑P3,rich and realistic color reproduction
  • eDP 1.4 (4 Lanes), 40 pins
  • Unique long‑strip design, perfect for auxiliary/secondary screen
  • High stability & reliability, suitable for industrial control & gaming monitors
  • Slim and compact structure, easy for device integration & assembly
Technical Specifications
Item Specification Key Points
Panel Brand BOE Original brand, stable quality & mass production
Model Number NV127H4M-NX1 Standard industrial model, reliable supply
Display Size 12.7-inch Ultra-wide bar type, unique form factor
Resolution 2880(RGB) × 864, 237 PPI High resolution, delicate and clear image
Panel Type a-Si TFT-LCD, ADS Full viewing angle, stable color performance
Aspect Ratio 30:9 Native ultra-wide strip, no stretching
Active Area 308.448(W) × 92.534(H) mm Standard effective display area
Outline Size 313.54(W) × 101.33(H) × 4.3(D) mm Compact structure, easy integration
Brightness 500 cd/m² (Typ.) High brightness, readable in bright environments
Contrast Ratio 1200:1 (Typ.) Strong image layering, clear black and white
Viewing Angle 89/89/89/89 (Typ.) Full viewing angle, no color shift
Response Time 25 ms (Typ.) Smooth motion, low blur
Refresh Rate 120 Hz High refresh, fluent display
Color Gamut 100% DCI-P3, 16.7M Colors Professional color performance
Surface Treatment Hard Coating (3H) Scratch resistant, durable
Backlight WLED 10S6P, 15K hrs, with driver Integrated driver, simplified design
Interface eDP 1.4 (4 Lanes), 40 pins High-speed transmission, strong compatibility
Input Voltage 3.3V (Typ.) Low power, energy saving
Thickness 4.3 mm (≤3.0 mm bent PCBA) Ultra-slim, suitable for slim devices
Touch No Touch Standard version, customizable
Operating Temp 0 ~ 50°C Wide temperature, industrial compatible
Storage Temp -20 ~ 55°C Good adaptability for transportation
Application Scenarios
  • Laptop secondary display / Dual-screen notebook
  • Portable ultra-wide bar monitor
  • Desktop auxiliary screen (system monitoring, streaming data)
  • Industrial control panel & equipment display
  • Automotive co-pilot / rear entertainment screen
  • Retail shelf digital signage
  • Medical monitoring equipment
  • Smart home control panel
  • Railway & aviation information display
Customization Options

Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include AR (Anti-Reflective), AF (Anti-Fingerprint), and AG (Anti-Glare). Can be equipped with HDMI driver boards for simplified customer debugging and evaluation.

Optional industrial-grade capacitive touch or resistive touch.
