BOE Original 5.0 Inch Round LCD Display Module with 1080x1080 Resolution and MIPI Interface for Home Appliance

Name: BOE Original 5.0 Inch Round LCD Display Module with 1080x1080 Resolution and MIPI Interface for Home Appliance
Brand: Shenzhen Wanshujie Photoelectric Technology Co., Ltd.
SKU: ZS050YMM-J40
Price: 29.00 USD
Availability: InStock

Brand Name:	BOE
Model Number:	ZS050YMM-J40
MOQ:	1
Price:	$58/pieces 1-99 pieces
Payment Terms:	L/C,D/A,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Panel Type:

A-Si TFT-LCD, LCM

Display Size:

5.0inch

Supplier Type:

Original Brand

Resolution:

1080(RGB)×1080 215PPI

Module Outsize(mm):

136.531(H)×132.208(V) ×3.48(D) Mm

Viewing Angle:

80/80/80/80 (Typ.)(CR≥10)

Support Color:

16.7M 70% NTSC

Brightness:

350cd/m2

Contrast Ratio:

1300:1 (Typ.) (TM)

Lamp Type:

WLED , 30K Hours , W/O Driver

Interface:

MIPI (4 Data Lanes) , 50 Pins Connector

Power Supply:

1.8/5.0/-5.0V (Typ.)(IOVCC/VSP/VSN)

Touch Screen:

Without

Application:

Round Display,Home Appliance,Instrument & Meters

Warranty:

12 Months

Highlight:

MIPI 5 inch round lcd display

BOE 5 inch round lcd display

1080x1080 round display module

Product Description

ZS050YMM-J40

BOE Original 5.0 Inch Round TFT Display Module with 1080×1080 resolution, designed for demanding industrial applications requiring reliable visual performance in various environmental conditions. Mass production started in Q4 2019.

Key Features

1080×1080 resolution with 215 PPI for clear, detailed imagery
350 cd/m² brightness display for excellent visibility
ADS technology with 80/80/80/80 viewing angles
MIPI interface with 50-pin connector for reliable data transmission
1300:1 contrast ratio for superior image quality
WLED backlight with 30,000 hours lifespan
16.7M color support with 70% NTSC color gamut
Wide operating temperature range: -30°C to 75°C
Round display format for specialized applications

Technical Specifications

Panel Model	ZS050YMM-J40
Panel Brand	BOE
Size	5.0 inch
Panel Type	a-Si TFT-LCD, LCM
Resolution	1080(RGB)×1080, 215 PPI
Pixel Format	RGB Vertical Stripe
Module Dimensions	136.531(W)×132.208(H)×3.48(D) mm
Display Mode	ADS, Normally Black, Transmissive
Active Area	127.008(W)×127.008(H) mm
Response Time	40ms (Typ.)(Tr+Td)
Display Colors	16.7M, 70% NTSC
Light Source	WLED, 30K hours, With LED Driver
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Touch Screen	Without
Brightness	350 cd/m² (Typ.)
Power Supply	1.8/5.0/-5.0V (Typ.)(IOVCC/VSP/VSN)
Contrast Ratio	1300:1 (Typ.) (TM)
Frame Rate	60Hz
Interface Type	MIPI (4 data lanes), 50 pins Connector
FPC Connector	HRS, IS100-L30O-C23, Pitch 1.0mm
Storage Temperature	-20°C to 60°C
Operating Temperature	-30°C to 75°C

Primary Applications

Home Appliance Instrument & Meters Round Display Commercial Round Display Digital Signage Outdoor Displays Elevator Display

Customization Options

Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include AR (Anti-Reflective), AF (Anti-Fingerprint), and AG (Anti-Glare). Can be equipped with HDMI driver boards for simplified customer debugging and evaluation.
