10.4" Rugged Transparent TFT Display 1024x768 XGA AT104XH11 Mitsubishi

10.4" Rugged Transparent TFT Display 1024x768 XGA AT104XH11 Mitsubishi

Brand Name:	Mitsubishi
Model Number:	AT104XH11
MOQ:	1
Price:	$425 for 1-99pcs
Payment Terms:	L/C,D/A,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Panel Type:

A-Si TFT-LCD, LCM

Display Size:

10.4"

Brand:

Mitsubishi

Supplier Type:

Original Brand

Pixel Format:

RGB Vertical Stripe

Treatment:

Antiglare, Hard Coating (3H)

Brightness:

1300 Cd/m² (Typ.)

Contrast Ratio:

700:1 (Typ.) (TM)

Response Time:

4/12 (Typ.)(Tr/Td)

Operating Mode:

TN, Normally White, Transmissive

Touch Panel:

Without

Power Supply:

3.3V (Typ.)

Light Source:

WLED , 100K Hours , W/O Driver

Interface Type:

LVDS (1 Ch, 6/8-bit) , 20 Pins Connector

Environment:

Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 M/s²)

Applications:

Rugged Industrial Outdoor High Brightness Industrial

Warranty:

12 Months

Packaging Details:

20pcs/Box

Highlight:

Rugged transparent tft display

1024x768 transparent tft display

AT104XH11

Product Description

AT104XH11 10.4" Industrial Display Module

High-performance 10.4-inch TFT-LCD display panel with 1024×768 XGA resolution, designed for demanding industrial applications requiring reliable visual performance in wide temperature environments.

Product Status: This model started mass production in Q1 2009 and has been discontinued. We recommend open mold customization as a complete replacement solution. Please contact us for ordering information.

Key Features

1024×768 XGA resolution with 123 PPI for clear, detailed imagery
1300 cd/m² high brightness display for excellent visibility
TN technology with 80/80/80/80 viewing angles
LVDS interface with 20-pin connector for reliable data transmission
700:1 contrast ratio for superior image quality
WLED backlight with 100,000 hours lifespan
262K/16.7M color support with 49% NTSC color gamut
Wide operating temperature range: -40°C to 85°C

Technical Specifications

Brand	Mitsubishi
Model P/N	AT104XH11
Diagonal Size	10.4"
Panel Type	a-Si TFT-LCD LCM
Resolution	1024(RGB)×768, XGA 123PPI
Active Area	210.4(W)×157.8(H) mm
Outline Dimensions	230.2(H)×180.2(W)×11.5(D) mm
Luminance	1300 cd/m² (Typ.)
Contrast Ratio	700:1 (Typ.)
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Support Color	262K/16.7M 49% NTSC
Interface Type	LVDS (1 ch, 6/8-bit), 20 pins Connector
Operating Temperature	-40°C to 85°C
Storage Temperature	-40°C to 85°C

Applications

Industrial equipment and machinery
Healthcare medical devices
Outdoor & rugged displays
Elevator Display
Security Monitor Display
Automation Equipment Display
CNC Machine Display

Customization Options

Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include AR (Anti-Reflective), AF (Anti-Fingerprint), and AG (Anti-Glare). Can be equipped with HDMI driver boards for simplified customer debugging and evaluation.
