BOE 33" Splicing Screen IPS LCD Module 1920×1920 420 nits WLED LVDS 92 pins
BOE 33 inch splicing screen LCD module
,IPS LCD display 1920x1920 resolution
,WLED LVDS stretched bar display
System Category: LCD/OLED/EPD Panel Module > TFT-LCM Module
Product Brand: BOE
Product range: DV332X2M
Product Model: DV332X2M-NV0
Key Description: BOE 33" Splicing Screen IPS LCD Module 1920×1920 420nits WLED LVDS 92pins
Product Category: Graphic Type
Product Tags: Color TFT LCD screen, square LCD screen, IPS LCD screen
Application products: digital signage, video wall, square display
Panel Type: a-Si TFT-LCD
Product composition: LCD module
Panel Size: 33"
Discrimination rate: 1920×1920
Aspect ratio: 1:1 (width:height)
Physical shape: Flat rectangle
Display Dimensions: 596.16 (W) × 596.16 (H) mm (A.A)
Exterior dimensions: 612.96 (W) × 612.96 (H) mm
LCD family: IPS hard screen
Polarizer: transmissive
Panel Brightness: 420 (Typ.)
Transmission Contrast: 1000:1 (Typ.)
Viewing Angle: 89/89/89/89 (Typ.) (CR≥10) (Left/Right/Up/Down)
Viewing Direction: Full view
Display color: 16.7M
Backlight Type: WLED
Signal Type: LVDS
Number of Pins: 92 Pins
Touch screen: No touch
Operating temperature: 0 ~ 50 °C
Storage temperature: -20 ~ 60 °C
-
